The world’s smallest and lightest 20,000-lumen 4K projector1.

The EB-PQ2220B large venue 4K laser projector features the latest Epson® technology—pioneering an unprecedented level of performance. The world’s smallest and lightest 20,000-lumen 4K projector1, the energy efficient EB-PQ2220B produces captivating visuals in extraordinary detail. Leveraging our 4K Crystal Motion technology, thermo-control panel and double micro-lens array, the EB-PQ2220B delivers stunning 4K resolution on-screen. With a high native contrast ratio and 3-chip 3LCD technology, you will enjoy a realistic display enriched with vibrant colors and deep blacks.

Designed for fixed installation applications and to meet the rigorous demands of live events, the EB-PQ2220B features a filterless cabinet, IP5X-rated hermetically sealed optical and light source unit, and a virtually maintenance-free 20,000-hour laser light source2. The projector provides frame interpolation for fast-moving objects, as well as HDR support3 and scene adaptive gamma correction for lifelike images. The EB-PQ2220B pairs with 9 optional powered lenses (sold separately) to simplify installation and includes a host of premium features for fast setup, such as built-in NFC functionality4, and an optional attachable PixAlign™ camera to streamline multi-projector setups.

      • World's smallest and lightest 20,000-lumen 4K projector1
      • 20,000 lumens of equal white and color brightness5
      • 4K Crystal Motion technology
      • Virtually maintenance-free 20,000-hour laser light source2
      • High native contrast for a realistic display


      THROW DISTANCE AND DISPLAY SIZE CALCULATORS ►
  • Model: V11HB05820
Request More Info
Find Accessories Support Download Brochure View Service Plans
The world's smallest and lightest 20,000-lumen 4K projector1
produces incredibly bright images with a light, compact and energy efficient design
Incredible color
Epson® 3-chip 3LCD technology produces 20,000 lumens of equal white and color brightness5
4K resolution on-screen
leverages Epson’s 4K Crystal Motion technology, thermo-controlled panel and double micro-lens array for crystal clear image quality that fully realizes 4K resolution (3840 x 2160)
Robust, high-reliability design
virtually maintenance-free 20,000-hour laser light source2; IP5X-rated hermetically sealed optical and light source module for high dust resistance; filterless cabinet; optimized liquid cooling system
Stunning image quality
high native contrast ratio for deep blacks; 50 percent improvement over the already high contrast ratio found with the current Epson EB-PU Series; frame interpolation for fast moving objects; HDR support3 and scene adaptive gamma correction 
Simplified installation
9 optional powered lenses (sold separately) including ultra short throw .35 throw lens with a unique zero offset design for installation flexibility; projector compatible with existing Epson lens family
  • Enhanced connectivity — HDMI® two in and one out; 12G-SDI in/out for daisy chaining and signal monitoring; features automatic input switching when input signal is disrupted
  • Versatile power source options — requires 220 V power for full brightness; can operate at 16,000 lumens from a standard 120 V power source for setup and installation
  • Low latency performance and high frame rate support — high-speed graphics chip and panel drive technology enable high frame rate 4K playback
  • Optional attachable PixAlign external camera — access powerful automated tools including edge blending assist6, stacking assist function6, auto color calibration7 and screen matching7 with or without a connected PC and router
  • Efficient setup and management — control multiple projectors in a single, large space with Epson Projector Professional Tool (EPPT app)8; easily manage your installed inventory using Epson Projector Management – Connected (EPM-C)9 from any device with a Web browser
  • NFC function built-in4 — reduce installation time of multiple projectors; read and write setting information using Epson’s mobile app

Eco Features

  • RoHS compliant
  • End-of-life options available10
  • Epson America, Inc. is a SmartWay® Transport Partner11

What's in the box:

  • EB-PQ2220B projector
  • two cables (200 V – 240 V power cable x 1 and 100 V – 120 V power cable x 1)
  • remote control with 2 batteries
  • cable cover
  • quick reference guide
  • warranty sheet

Service Plans:

EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector

We know protecting your investment is important. Epson Preferred Plus Extended Service Plans offer peace of mind beyond the device’s limited warranty and help keep you up and running — because we understand there’s simply no time for downtime.

Learn More

Need Support?

Get the latest drivers, FAQs, manuals and more for your Epson product.

Go to Support

Notes:

1 Comparison based on 4K projectors rated at 20,000 lumens. Lumens, resolution, size and weight based on the manufacturers' online specifications and industry-available data as of October 2023.
2 No required maintenance for the light source for up to 20,000 hours. Approximate time until brightness decreases 50% from first usage. Measured by acceleration test assuming use of 0.04 - 0.20 mg/m3 of particulate matter. Time varies depending on usage conditions and environment. Replacement of parts other than the light source may be required in a shorter period.
3 HDR performance available with select third-party devices. For more information, see www.epson.com/hdrcompatibility
4 NFC requires use of a device that includes NFC and may require additional software.
5 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
6 Requires Epson external camera for each projector and may require Epson Projector Professional Tool app.
7 Using separate camera for each projector.
8 Mac® and PC only.
9 Requires one on-site PC with Epson Projector Connected Agent installed.
10 For convenient and reasonable recycling options, visit www.epson.com/recycle
11 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
